Two things happened this week. The §5.21 catalogue runner merged to main as PR #124 — 2472 tests green, governance check passed, squash-merged as 5a425aca. And the first live RF went through SCYTHE’s measurement machinery. Not as catalogue evidence. As the shakedown the machinery deserved: three terminated-input windows, three escalating traumas to the USB bus, and one tone that survived all of them.
The runner lands, and refuses
PR #124 carried rf_spur_catalogue_runner.py and rf_spur_retention_estimator.py onto main: the sequencer, the retention estimator, the authorisation record, the protocol governance. The curated suite ran 2472 tests at the branch tip with two host skips and zero failures. The governance check passed on the merge commit.
The most important thing the runner does is refuse. Point it at a window with no catalogue behind it and it answers RUNNER_SPUR_CATALOGUE_ABSENT — no formal verdict, no manufactured declaration, no path from “I captured something” to “the catalogue says.” That refusal is correct behavior, and everything below was produced under it. Nothing in this post is a catalogue declaration. The three windows are classified PRE_CATALOGUE_EVIDENCE, and the runner’s refusal stands over all of them.
Three windows, no antenna
The SMA-male 50 Ω termination load stayed fitted through all three captures; the telescopic antenna stayed off. Each window is 120 seconds of uint8 I/Q at 2.048 MS/s, 100 MHz LO, from the NESDR SMArt v5 (serial 14530058) on the SDR-side host:
- E1 — INITIAL_SESSION, site 12426. The dongle as found.
- E2 — RECONNECT, site 12502. Software USB detach/reattach between captures. Nothing else touched.
- E3 — POWER_CYCLE, site 12502. Physical unplug/replug of the dongle between captures.
The operator seed was verified independently before any of this: BLAKE2s-8 of the declaration ASCII yields 68926329f9fff6c4, i.e. u64be 7535194158483371716 — matching the declaration exactly, with no measurement entering the derivation. All three .iq files transferred byte-exact (491,520,000 bytes each) with SHA-256 verified at both ends of every hop, and they now rest on the analysis host alongside their sidecars and checksum manifests.
The tone
Every window shows the same empirical character: a thermal-like floor plus one persistent unresolved narrow feature. The numbers, from averaged periodograms over 2^18-sample blocks (7.8125 Hz per bin, 937 blocks per window):
| epoch | floor | peak | excess | occupied width |
|---|---|---|---|---|
| E1 | 68.62 dB | 100799968.8 Hz | +39.62 dB | 85.9 Hz |
| E2 | 68.76 dB | 100799968.8 Hz | +39.83 dB | 85.9 Hz |
| E3 | 68.99 dB | 100799968.8 Hz | +40.00 dB | 85.9 Hz |
The peak sits in the identical bin in all three epochs — no detected shift at 7.8125 Hz resolution. The ±1 kHz cutout shapes cross-correlate at 0.998 or better between every pair, maximum at zero lag. Same bin, same shape.
Going in, the epoch-3 outcome had three branches: same bin and shape would mean persistent across reconnect and power cycle; disappearance would mean power-cycle-state dependent; movement would mean preserving both frequencies and reading the direction. Branch one is what the data gave. The feature is persistent across reconnect and power cycle.
Note the arithmetic, recorded without interpretation: 100.8 MHz is 3.5 × 28.8 MHz, and a reference comb is integer harmonics only — so this tone can never be CONSISTENT_WITH_INTERNAL_REFERENCE. If the retune experiment shows it receiver-relative, the investigation goes to fractional/divider/PLL mixing products, not the comb.
The temperature wrinkle
The feature’s excess rises monotonically across the three epochs: +39.62, +39.83, +40.00 dB. The floors creep too: 68.62, 68.76, 68.99 dB. Temperature drift is the obvious suspect — the NESDR runs hot — and the numbers are consistent with it, with one wrinkle worth naming: the floor rose +0.37 dB while the feature rose +0.75 dB absolute. Pure common-mode gain drift would leave the excess over the floor flat. It isn’t flat, so temperature is plausibly moving both the chain gain and whatever couples this spur in.
That is an observation, not an interpretation. The discriminators are cheap: log USB flap timestamps against dongle uptime, put a thermometer near the enclosure, and run the powered-hub test to separate port power droop from the dongle’s own thermals. Heat is one live hypothesis for the flaps; the usbipd attach layer is another, and the 006→007 node hop during re-attach is its signature. Both stories stay on the table until the data picks one.
Operationally, the catalogue’s bounded 120-second captures don’t need full-time streaming — rtl_tcp idling hot between captures is thermal cost with no evidentiary return. Full-time operation (a public stream, an ambient survey) will need heat management as a design input: airflow, a powered hub, and a liveness watchdog for the silent-but-active wedge state, so a 3 a.m. thermal flap becomes a logged event instead of a lost night.
What it doesn’t prove
No origin is assigned to the tone. Internal product and ambient ingress are both still permitted by the evidence, and the prose stays inside that discipline deliberately: “persistent across reconnect” is an empirical description, never the catalogue stability class. The retune experiment — same terminated input, different LO — is the discriminator, and it hasn’t run yet.
Two gates stand ahead of the real catalogue run. The reference gate is undeclared and iron-clad: nominal-reference authority needs unit-specific evidence (a PCB/TCXO marking or a direct measurement of this exact unit), and the ±0.5 ppm figure stays or goes on the strength of a unit calibration, not a datasheet. Until that gate clears, the K=64/R=8 capture schedule is not authorized to execute. The machine that learned to refuse will keep refusing, and that’s the whole point.
The three windows, their sidecars, and the checksum manifests are archived on the analysis host. The comparison analyzer is a streaming memmap implementation — the load-whole-file version was OOM-killed at three full-window FFTs, which is its own small lesson about this hardware.
